Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Kategori: | Rakitan Motor Ayun | Model mesin: | SK250-6E SG08 |
|---|---|---|---|
| Aplikasi: | Alat berat | Nama produk: | Piring |
| Nomor Bagian: | LQ15V00015S008 LQ15V00015S009 | Pengemasan: | Karton ekspor standar |
| Aplikasi | Peralatan Berat |
| Nama | pelat |
| Bagian No | LQ15V00015S008 LQ15V00015S009 |
| Model Mesin | SK250-6E SG08 |
| Kategori | Bagian-bagian perakitan mesin ayunan |
| Waktu lead | 1-3 hari |
| Kualitas | Baru, kualitas OEM |
| MOQ | 1 PCS |
| Alat transportasi | Perjalanan laut/udara, DHL FEDEX UPS TNT EMS |
| Pengemasan | Sesuai permintaan atau kemasan standar |
Peralatan berat SK235SR-1E SK235SR-1ES SK235SR-2 SK235SRLC-1E SK235SRLC-1ES SK235SRLC-2 SK235SRNLC-1E SK235SRNLC-1ES SK250LC-6E SK260 SK485-8 SK485-9 SK485LC-9 Kobelco
| LQ15V00007S092 PLATE |
| SK235SR-1E, 230SR-3, SK235SR-1ES, 260SR-3, SK235SR-2, SK210-9, SK235SRLC, SK235SRLC-1E, SK235SRLC-1ES, SK210LC-6E, SK235SRLC-2, SK235SRNLC-1E, SK250LC, SK250LC-6E, SK260, SK235SRNLC-1ES, SK260-9 |
| LQ15V00007S096 PLATE |
| SK235SR-1E, 230SR-3, SK235SR-1ES, 260SR-3, SK235SR-2, SK210-9, SK235SRLC, SK235SRLC-1E, SK235SRLC-1ES, SK210LC-6E, SK235SRLC-2, SK235SRNLC-1E, SK250LC, SK250LC-6E, SK260, SK235SRNLC-1ES, SK260-9 |
| LQ15V00020S088 PLATE |
| SK170-9, SK260, SK170 ACERA M-9, 230SR-3, 260SR-3, SK235SRLC-2, SK235SR-2, SK210-9, SK235SR-1E, SK260-9 |
| LQ15V00007S060 PLATE |
| SK235SR-1E, 230SR-3, SK235SR-1ES, 260SR-3, SK210-9, SK235SRLC, SK235SRLC-1E, SK235SRLC-1ES, SK210LC-6E, SK235SRNLC-1E, SK250LC, SK250LC-6E, SK235SRNLC-1ES, SK260-9, SK170 ACERA M-9, SK170-9, SK235SR |
| YN15V00005S105 PLAT |
| SK235SRLC-1E, SK235SR-1E, SK235SRNLC-1E, SK235SRNLC-1ES, SK235SRLC-1ES, SK210LC-6E, SK235SR-1ES, SK235SR, SK235SRLC, SK250LC, SK250LC-6E |
| LQ15V00007S087 PLATE |
| SK235SRLC-1E, SK235SR-1E, SK235SRNLC-1E, SK235SRNLC-1ES, SK235SRLC-1ES, SK210LC-6E, SK235SR-1ES, SK235SR, SK235SRLC, SK250LC, SK250LC-6E |
| LQ15V00007S097 PLATE |
| SK235SRLC-1E, SK235SR-1E, SK235SRNLC-1E, SK235SRNLC-1ES, SK235SRLC-1ES, SK210LC-6E, SK235SR-1ES, SK235SR, SK235SRLC, SK250LC, SK250LC-6E |
| LQ15V00007S046 PLATE |
| SK235SRNLC-1E, SK235SRLC-1E, SK235SRNLC-1E, SK235SRNLC-1ES, SK235SRLC-1ES, SK235SR-1ES, SK250LC-6E |
| LQ15V00020S043 PLATE |
| SK260, SK260-9, 260SR-3, SK235SRLC-2, SK235SR-2, SK235SR-1E |
| LQ15V00020S074 PLATE |
| SK235SR-2, SK235SRLC-2, SK260, SK235SR-1E |
| LC10V00010S153 PLATE |
| SK295-9, SK260, SK260-9, SK330LC-6E, SK350-9, SK350-8, SK295-8 |
| LE60C01029P1 PLAT |
| SK235SRLC-1E, SK235SR-1E, SK235SRNLC-1E, SK215SRLC, SK235SRNLC-1ES, 230SR-3, SK235SRLC-1ES, SK235SR-1ES, SK235SRLC-2, SK235SR-2, 260SR-3 |
| Posisi. | Bagian No. | Qty | Nama bagian | Komentar |
| . . | LQ15V00015F2 | [1] | Motor hidraulik, 151CC | KOB ASSY-Swing |
| 1 | LQ15V00015S001 | [1] | SNAP RING | KOB |
| 2 | LQ15V00015S002 | [1] | OIL SEAL | KOB SPRING |
| 3 | LQ15V00015S003 | [1] | ROLLER BEARING | KOB ROLLER |
| 4 | LQ15V00015S004 | [1] | Tempat duduk SPRING | KOB SPRING |
| 5 | LQ15V00015S005 | [1] | PELAT | KOB |
| 6 | LQ15V00015S006 | [1] | PELAT | KOB |
| 7 | NSS | [9] | TIDAK DIJUAL SEPARAT | CON PISTON |
| 8 | LQ15V00015S008 | [3] | PELAT | KOB |
| 9 | LQ15V00015S009 | [3] | PELAT | KOB |
| 10 | LQ15V00015S010 | [1] | O-RING | KOB Digantikan oleh nomor bagian: 45Z91D91 |
| 11 | LQ15V00015S011 | [1] | Piston | KOB PISTON |
| 12 | LQ15V00015S012 | [1] | O-RING | KOB |
| 13 | LQ15V00015S013 | [19] | SPRING | KOB |
| 14 | LQ15V00015S014 | [2] | Piston | KOB |
| 15 | 2436U1309S41 | [3] | PDB | KOB PLUG |
| 16 | ZD12P01100 | [3] | O-RING | KOB ID 10,8mm x OD 13,2mm |
| 17 | 2441U455S53 | [2] | PIN | KOB |
| 18 | LQ15V00015S018 | [4] | WASHER, LOCK | KOB |
| 19 | LQ15V00015S019 | [4] | RING | KOB |
| 20 | LQ15V00015S020 | [4] | BUSHING | KOB |
| 21 | LQ15V00015S021 | [1] | PELAT | KOB |
| 22 | LQ15V00015S022 | [1] | PEMANGAT jarum,45mm ID x 33mm OD x 20mm W | KOB jarum |
| 23 | LQ15V00015S023 | [1] | RING | KOB RETENING |
| 24 | NSS | [1] | TIDAK DIJUAL SEPARAT | CON CYLINDER |
| 25 | NSS | [1] | TIDAK DIJUAL SEPARAT | CON |
| 26 | LQ15V00015S026 | [1] | RING | KOB Collar |
| 27 | LQ15V00015S027 | [1] | SNAP RING | KOB RETENING |
| 28 | LQ20V00001F1 | [2] | VALVEL HIDRAULIK | KOB |
| 29 | LQ15V00015S029 | [1] | O-RING,183.74mm ID x 3.53mm Lebar | KOB |
| 32 | NSS | [1] | TIDAK DIJUAL SEPARAT | CON COVER |
| 33 | LQ22V00002F1 | [2] | VALVEL HIDRAULIK | KOB RELIEF |
| 35 | ZS23C16060 | [4] | Screw, Hex Socket Head, M16 x 60mm | KOB M16x2.0x60mm |
| 36 | 2441U962S45 | [2] | VALVE CEK | KOB |
| 37 | 2441U962S46 | [2] | SPRING | KOB |
| 38 | 2441U962S48 | [2] | PLUG | KOB |
| 39 | ZD85P02600 | [2] | RING BACKUP | KOB ID 26 x OD 32 x Th 1,25mm |
| 40 | LP15V00002S027 | [1] | PLUG | KOB |
| 41 | PH15V00004S013 | [2] | Piston | KOB |
| 42 | PH15V00004S012 | [2] | RING | KOB |
1 Bagian hidraulik: pompa hidraulik, katup utama, silinder hidraulik, drive akhir, motor perjalanan, mesin ayunan, motor ayunan dll.
2 Bagian mesin: mesin, piston, ring piston, blok silinder, kepala silinder, poros engkol, turbocharger, pompa injeksi bahan bakar, motor pemicu dan alternator dll.
3 Bagian bawah kereta: Rol Track, Rol Carrier, Track Link, Sepatu Track, Sprocket, Idler dan bantalan Idler dll.
4 Bagian kabin: kabin operator, kabel kabel, monitor, pengontrol, kursi, pintu dll.
5 Bagian pendingin: radiator, AC, kompresor, after cooler dll.
6 Bagian lain: Kit layanan, lingkaran ayunan, kap mesin, sendi ayunan, tangki bahan bakar, filter, boom, lengan, ember dll.
Keuntungan
1. Menawarkan produk berkualitas tinggi & kompetitif
2. Dukungan garansi 12 bulan
3. 100% diuji sebelum pengiriman
4Pengiriman tepat waktu.
5. Berbagai sensor tekanan minyak, Fuel Tank Level Sensor, Sensor Suhu, Sensor Kecepatan untuk excavator
6. Lebih dari 15 tahun produksi dan 11 tahun pengalaman perdagangan luar negeri
7Tim QC profesional.
8Tim penjualan terbaik, layanan 24 jam.
Rincian kemasan:
Kemasan dalam: film plastik untuk pembungkus
Pengemasan luar: kayu
Pengiriman:
Dalam waktu 3 hari setelah menerima pembayaran, melalui udara atau ekspres atau laut berdasarkan
jumlah dan keadaan darurat.
1. Dengan kurir: DHL, UPS, FEDEX, TNT adalah perusahaan kurir utama kami bekerja sama,
2. Dengan Air: Pengiriman dari bandara Guangzhou ke bandara kota tujuan pelanggan.
3Dengan laut: Pengiriman dari pelabuhan Huangpu.
